we specialize in computer accessories and so on. it is original parts please buy with confidence.Description
2x sata cable(free gift).
1 xI/O back panel.
The above pictures are for reference only.
itemintroduction
CPU
- Supports AMD AM4 socket Ryzen™ 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop processors*
*Not compatible with AMD Athlon™ AMD B550
RAM
- Dual channel DDR4 memory technology
- 2 x DDR4 memory slots
- AMD Ryzen series processors (Vermeer) support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) ) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & (non- ECC), un-buffered memory*
- AMD Ryzen series processors (Matisse) support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) ) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & (non- ECC), un-buffered memory*
- AMD Ryzen series APU (Cezanne) supports DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & (non-ECC), un-buffered memory*
- AMD Ryzen series APU (Renoir) supports DDR4 4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & (non-ECC), un-buffered memory*
- AMD Ryzen series APU (Picasso) supports DDR4 3533+(OC) / 3466(OC) / 3200(OC) / 2933 / 2667 / 2400 / 2133 (non-ECC), un-buffered memory*
- Maximum system memory capacity: 64GB**
- Supports Extreme Memory Profile (XMP) memory modules
- DIMM sockets feature 15µ gold plated headers*
BIOS
- 256Mb AMI UEFI Legal BIOS with GUI support
- Support "Plug and Play"
- Compliant with ACPI 5.1, supports Wake Up Events
- Support jumper-free
- Support SMBIOS 2.3
- CPU, CPU VDDCR_SOC, DRAM, VDDP voltage multi-function regulator
Onboard graphics card
- Integrated AMD Radeon™ HD Vega series graphics cores on Ryzen series APUs*
- DirectX 12, Pixel Shader 5.0
- Shared memory defaults to 2GB. Supports up to 16GB of shared memory. **
- Three display output options: D-Sub, DVI-D and HDMI
- Supports simultaneous output of three monitors
- Supports HDMI 2.1, up to 4K x 2K (4096x2160) @ 60Hz
- Support DVI-D, maximum resolution up to 1920x1200 @ 60Hz
- Supports D-Sub, up to 1920x1200 @ 60Hz
- Supports HDMI port automatic audio and video sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) 2.1 interface (requires HDMI compatible monitor)
- Supports HDR (High Dynamic Range) with HDMI 2.1
- Supports HDCP 2.3 via DVI-D and HDMI 2.1 ports***
- Supports 4K Ultra HD (UHD) playback via HDMI 2.1 port
- Support for Microsoft® PlayReady
*Actual level of support depends on CPU
**To get up to 16GB of shared memory requires 32GB of system memory installed.
***Picasso supports HDCP 2.2 capability via HDMI 2.0 port
Sound effect
- 7.1 channel high definition audio (Realtek ALC887 audio codec)
- Support anti-surge
local area network
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111H
- Support Wake-On-LAN function
- Support anti-lightning/anti-ESD static electricity
- Supports Energy Efficient Ethernet 802.3az
- Support PXE
Expansion slot
AMD Ryzen series processors (Vermeer and Matisse)
- 1 x PCI Express 4.0 x16 slot (PCIE1: x16 mode)*
AMD Ryzen series APUs (Cezanne and Renoir)
- 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)*
AMD Ryzen Series APUs (Picasso)
- 1 x PCI Express 3.0 x16 slot (PCIE1: x8 mode)*
- 1 x PCI Express 3.0 x1 slot
*Support NVMe SSD boot
Storage
- 4 x SATA3 6.0 Gb/s ports, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and hot plug
- 1 x Super M.2 port, supports M Key 2242/2260/2280 type M.2 SATA3 6.0 Gb/s and M.2 PCIe modules to Gen4x4 (64 Gb/s) (Vermeer, Matisse) or Gen3x4 (32 Gb /s) (with Cezanne, Renoir and Picasso)*
*Support NVMe SSD boot
Support ASRock U.2 kit
Onboard interface
- 1 x SPI TPM header
- 1 x COM port header
- 1 x Chassis open warning function header and speaker header
- 1 x CPU Fan Connector ((4-pin))*
- 2 x Chassis Fan Connectors ((4-pin)) (Smart Fan Speed Control)**
- 1 x 24-pin ATX power connector
- 1 x 4-pin 12V power connector
- 1 x front panel audio jack
- 2 x USB 2.0 pin headers (supports 4 USB 2.0 ports) (supports ESD protection)
- 1 x USB 3.2 Gen1 header (supports 2 USB 3.2 Gen1 ports) (supports ESD protection)
*CPU fan connector supports up to 1A (12W) power supply.
**The case fan supports a water cooling fan with a maximum fan power of 1A (12W).
CHA_FAN2 can automatically detect 3-pin or 4-pin fans.
I/O port on the rear panel
- 1 x PS/2 keyboard/mouse port
- 1 x D-Sub connector
- 1 x DVI-D port
- 1 x HDMI port
- 2 x USB 2.0 ports (supports ESD protection)
- 4 x USB 3.2 Gen1 ports (supports ESD protection)
- 1 x RJ-45 network interface with indicator lights (action/connection indicator and speed indicator)
- HD Audio Jack: Line In / Front / Mic
Dimensions
- Micro ATX : 9.0-in x 7.9-in, 23.0 cm x 20.1 cm
Operating system
- Supports Microsoft® Windows 10 64-bit / 11 64-bit
