5er Link Technology 12 Strand MultiMode LC OM3 Fiber Optic Pigtails for Fusion
Product description Fiber Optic Pigtails
12 Strand
Our fiber optic pigtails are made of high-quality Single-mode, OS2, 9/125, Multi-mode 62.5/125 and 50/125 fiber optic cable with LC/UPC, LC/APC, SC/UPC, SC/APC, ST/UPC connectors. Ideal for fusion splicing, they are quality tested to meet or exceed industry standards while adhering to only the most stringent performance specifications.
- PVC flame-retardant fiber optic cable with tight-buffered coating on each optical fiber
- Optical testing insertion loss and return loss
- Individually colored to easily match color-coded fiber cable that will be spliced
- Support both fusion and mechanical splicing for fiber cabling system
Connector Type LC Fiber Type Multi Mode Polish Type UPC Fiber Count 12 Wavelength 850/1300 nm Insertion Loss ≤0.3 dB Return Loss ≥20 dB Minimum Bend Radius 10 mm Cable Diameter 0.9 mm Pigtail Color 12-Color Attenuation at 850nm 3.0 dB/km Attenuation at 1300nm 1.0 dB/km Reliable Transmission
The pigtail combines zirconia ferrules and rugged composite hardware to provide the optical performance, durability, and repeatability necessary for today's network applications.
LC Connector
A Lucent Connector (LC), as one SFF (small form factor) connector, possesses a 1.25 mm ferrule. The small footprint design gives these fiber optic connectors huge popularity in datacoms and makes them more ideal for high-density applications. Many tend to move to high-efficiency cabling with LC fiber connectors nowadays. LC fiber optic connector is considered the most commonly-used connector at present.
Mutimode Fiber
OM3 Multimode fiber is mostly used in communication over short distances, for example, inside a building or for the campus. These Multimode fiber optic pigtails have a core of 50 microns that enables multiple light modes to be propagated.
UPC Fiber Connector
UPC is the acronym for Ultra Physical Contact. It is an improvement of the PC fiber connector with a better surface finish after an extended polishing and the return loss is better than PC structure, nearly -50dB or higher. Though it has a relatively lower back reflection in comparison with the PC connector, it is not robust enough. Note that repeated connections and disconnections will bring about the degradation of the surface and ultimate performance.
Includes 12 Fiber Optic Fusion Splice Sleeves 60mm Long
5er Link Technology Fiber Optic Fusion Splice Sleeves enable to secure one or twelve fibers in one sleeve. Excellent climatic and thermal properties make it ideal for use in closed as well as open spaces. The sleeves we produce offer full protections the fiber optic splices. They do not cause additional insert losses, and they offer protection against mechanical damage, pollution and weather conditions. These protector sleeves provide a way to support and protect a fiber optic fusion splice. As the sleeve is somewhat rigid it does help provide some protection to the splice area. The protector sleeves themselves are easy to install which means the potential for damage to the splice is minimal. The splice sleeves are heat shrinkable. Once the fusion splicing has taken place and alignment is correct, heat is applied and the sleeve shrinks to provide protection to the splice.
- Low Insertion and Back Reflection Loss
- Ideal for use in Telecommunication Networks, LAN, WAN and Data Processing Networks
- Includes 12 Fusion Splice Protective Shrink Sleeves φ2.5 - 60mm long
- Fiber optic strands are Individually color coded
- Available in Single-mode and Multi-mode (LC, SC, ST and FC Connectors)
Item Specification
- Connector Type LC Cable Type Fiber Optic Compatible Devices Telephone Other Special Features of the Product Data Transfer, High Speed Compatible Phone Models Potentially compatible with smartphones, specific models unknown Connector Gender Male-to-Male Data Transfer Rate 10 gigabits_per_second Recommended Uses For Product fiber optic network connection and data transmission Indoor Outdoor Usage Indoor, Outdoor Item Shape Round Model 5ER-PTST12 Included Components Includes 12 Fusion Splice Protective Shrink Sleeves φ2.5 - 60mm long Part Number 5ER-PTST12 Unit Count 24 Count Number of Items 24 Special Feature Data Transfer, High Speed
