3 Lot 30GB Hitachi Travelstar 1.8" 4200RPM HTC426030G5CE00 P/N: 08K1569 ZIF Hard Drive

Manufacturer Part Number

HTC426030G5CE00, P/N: 08K1569

Product Line

Travelstar C4K60 Slim Series

Form Factor

1.8-inch internal hard drive, 5mm height

Storage Capacity

30 GB

Rotational Speed

4200 RPM (using a Fluid Dynamic Bearing motor for quiet operation)

Interface

PATA (EIDE Ultra-DMA ATA-7), also known as IDE Ultra ATA/100 (ATA-6)

Connector

ZIF (Zero Insertion Force) CE PATA 40-pin connector

Cache Buffer

2 MB

Maximum Data Transfer Rate

100 MB/s (Host to buffer)

Average Seek Time

15.0 ms (typical)

Dimensions (L x W x H)

71.0mm x 54.0mm x 5.0mm (approx. 2.8" x 2.1" x 0.2")

Weight

Approx. 46 grams (1.62 oz)

Shock Resistance (Operating)

600Gs / 2ms

Recording Technology

Perpendicular Magnetic Recording (PMR) Technology

• Portable Media Players: Notably the Apple iPod video and Creative Zen Vision M/W.
• Laptops/Notebooks: Compatible with laptops that utilized the 1.8-inch IDE ZIF interface.

ZIF Connector: The drive uses a Zero Insertion Force (ZIF) connector, a common interface for small form factor devices of its era, allowing for a slim 5mm profile.

Low Power Consumption: Designed with power efficiency in mind to extend battery life in portable devices.

High Shock Tolerance: Features an internal shock sensor and a high operating shock tolerance (600Gs) for mobile, "all-terrain" usage.
