The VS92A is a video splitter that not only duplicates the video signal from any VGA, XGA, SVGA, UXGA,or multisync monitor to four outputs, but also boosts the video signal over a distance of up to 30 meters.
Cascadable to support up to 64 displays, and offering bandwidth up to 350 MHz,the VS94A is ideal for broadcasting and enhancing video information to the public, monitoringyour work environments from safe locations, or offering superior video for company or classroom training.
Package Contents1x 2-Port Video Splitter1x Power Adapter1x User Instructions
Video Input
Interfaces 1 x HDB-15 Male (Blue)Impedance 75 ?Max. Distance 1.8 m
Video Output
Interfaces 2x HDB-15 Female (Blue)Impedance 75 ?VideoMax. Bandwidth 350 MHzMax. Resolution Up to 1920 x 1440Max. Distance Up to 30 m
Connectors
Power 1 x DC Jack
Power Consumption Temperature 0-50°CStorage Temperature -20 - 60°CHumidity 0 - 80% RH, Non-Condensing
Physical Properties
Housing MetalWeight 0.61 kg ( 1.34 lb )Dimensions (L x W x H) 20.00 x 7.51 x 4.40 cm(7.87 x 2.96 x 1.73 in.)
Note For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
