12/13/14th Gen LGA1700 CPU NAS Motherboard Q670 Intel vPro
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
12/13/14th Gen LGA1700 CPU NAS Motherboard Q670 Intel vPro
Price: CN $435.30
Item description from the seller Motherboard Features

    Matte black PCB

  • 8-layer high-density fiberglass circuit board

  • Full protection (supports all USB, audio, and network interfaces)

Processor

    Supports Intel 12th/13th/14th Gen LGA1700 desktop processors

  • Note:vPro functionality requires an i5-1X500 or higher processor (F-series not supported; requires integrated graphics).

  • Note:Default support for 125W TDP processors; K-series processors are not recommended.

  • Note:Recommended to use T-series processors (e.g., 13500T) for energy efficiency and long-term use.

Memory

    Supports desktop U-DIMM DDR5 memory (ECC not supported)

  • 4 × U-DIMM DDR5 dual-channel memory slots

  • DDR5 default support: 5600MHz (Note:12th Gen processors only support 4800MHz)

  • Max single stick: 32GB | Max motherboard support: 128GB

TDP

    Base power consumption: 125W

Storage

    2 × M.2 NVMe PCIe 4.0 x4 slots (2280-22110 compatible)

  • 12 × SATA3.0 (6Gbps) (expanded via three SFF-8643 interfaces)

Networking

    2 × Intel i226-V 2.5G RJ45 ports

  • 1 × Intel i226-LM 2.5G RJ45 port (supports vPro remote management)

Graphics

    Integrated graphics determined by CPU

  • PCI-E x16 slot supports various PCI-E graphics/network cards

  • HDMI 2.0: Supports 4K @ 4096×2160, 60Hz

  • DP 1.4: Supports 4K @ 4096×2160, 60Hz

  • VGA: Supports 1080P @ 60Hz

Onboard Interfaces

    1 × CPU-FAN header

  • 6 × SYS-FAN headers

  • 1 × 8-pin ATX power connector

  • 1 × 24-pin ATX power connector

  • 1 × USB 3.0 socket

  • 1 × Type-C socket

  • 1 × eDP display output

  • 2 × M.2 NVMe PCIe 4.0 x4 slots (2280 & 22110 compatible)

  • 3 × SFF-8643 interfaces (expandable to 12 SATA3.0 drives)

  • 4 × U-DIMM DDR5 slots

  • 2 × PCI-E x16 slots (runs at x8 speed if both are used)

  • 2 × PCI-E x4 slots

  • 2 × USB 2.0 vertical headers (for dongles/boot drives)

  • 1 × USB 2.0 pin header

  • 1 × CNVi Wi-Fi slot (supports AX201/211/401/411 cards only)

Rear I/O Panel

    1 × HDMI 2.0

  • 1 × VGA

  • 1 × DP 1.4

  • 1 × BIOS reset button

  • 1 × Type-C 3.2 Gen2×2 port (no display support)

  • 1 × Serial port (DB9)

  • 3 × 2.5G RJ45 ports

  • 2 × USB 2.0 ports

  • 4 × USB 3.0 ports

  • 2 × Audio jacks

Form Factor

    mATX: 9.6 × 9.6 inches (244 × 244 mm)

  • Solid-state capacitor design

Operating System

    Supports Microsoft Windows Server/10/11 64-bit

  • Linux compatible

  • EFI mode only
