10 Inch Rack Mount 2U for the GMKtec K8 Plus / K11 / M7 / M7 Pro / M7 Ultra
A 2U tray that seats a GMKtec K8 Plus, K11, M7, M7 Pro or M7 Ultra in a 10 inch mini rack, printed to order in matte black PETG. The PC slides in from the front, through the window, until it touches the two rear stop posts, and sits about 11 mm proud of the faceplate. It rests on an open honeycomb floor and the rear of the tray is open for cables. No adhesive, no modification to the PC.
Designed From The Published Specification
- Fits: GMKtec NucBox K8 Plus, K11, M7, M7 Pro and M7 Ultra, which GMKtec lists at the same 132 x 125 x 58 mm, inserted with the 125 mm front I/O panel forward (132 mm front to back).
- Why 2U: a 58 mm body plus the floor and its clearance is taller than a 1.5U (66.7 mm) faceplate allows.
- Opening 127 x 64 mm over a flush floor: 1 mm of side clearance and 6 mm above the 58 mm body, room for its rubber feet.
- Faceplate 248 mm wide on EIA-310 10 inch hole spacing; 2U (88.9 mm) tall.
Build
- Single piece.
- Vented rhythm-slot face and an open honeycomb floor.
- Fits any 10 inch / 254 mm mini rack with standard square or round holes. The mounting slots take M6, M5, #10-32 or M4 rack screws.
- Part measures 248 x 129 x 88.9 mm. Matte black PETG.
Printed To Order
Each unit is printed fresh in our shop on calibrated printers and inspected before it ships. Lead time is typically 1-3 business days. Minor layer lines are normal for FDM 3D printing and part of the finish.
Mount only. Mini PC and power adapter not included. The rack and the device shown in the photos are not included; they appear for scale and fitment only.
Not an official GMKtec product; GMKtec and NucBox are trademarks of their owner.
