MSI manufacturer refurbished unit, 120 days MSI direct warranty, comes with SATA cable, I/O shield, and Wi-Fi antenna.
ChipsetINTEL B760
CPUSupport Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
LGA 1700
Memory4x DDR5, Maximum Memory Capacity 256GB
Memory Support DDR5 4800 MHz (by JEDEC & POR)
Max. overclocking frequency:
• 1DPC 1R Max speed up to 6200+ MHz
• 1DPC 2R Max speed up to 5200+ MHz
• 2DPC 1R Max speed up to 4000+ MHz
• 2DPC 2R Max speed up to 4000+ MHz

Supports Intel®XMP 3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory
Slot4x PCI-E x16 slot (Qty)
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset)
AudioRealtek®ALC897 Codec
7.1-Channel High Definition Audio
Storage2x M.2 (Qty)
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
6x SATA 6G (Qty)
*SATA7 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
RAIDSupports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
*SATA_A1 & SATA_B1 do not support RAID function.
USB2x USB 2.0 (Rear)
4x USB 2.0 (Front)
4x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
1x USB 5Gbps Type C (Front)
1x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Rear)
LANRealtek®8125BG 2.5Gbps LAN
Internal IO1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
2x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Printer Port (JLPT)
1x Com Port (JCOM)
1x Tuning Controller connector(JDASH)
2x Addressable RGB LED connector(JRAINBOW)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
WIRELESS LAN & BLUETOOTHWi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth®5.3, FIPS, FISMA

* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 10 build 21H1 and Windows 11.
LED FEATURE4x EZ Debug LED
BACK PANEL PORTS

1. Keyboard / Mouse
2. 2.5G LAN
3. USB 3.2 Gen 2 10Gbps (Type-A)
4. Wi-Fi / Bluetooth
5. Audio Connectors
6. USB 2.0
7. USB 3.2 Gen 1 5Gbps (Type-A)
8. USB 3.2 Gen 2 10Gbps (Type-C)

OPERATING SYSTEMSupport for Windows®11 64-bit, Windows®10 64-bit
PCB InfomATX
243.84mmx243.84mm
