Anker 777 Thunderbolt Docking Station (Apex, 12-in-1, Thunderbolt 4) | Certified Refurbished

Anker 777 Thunderbolt Docking Station (Apex, 12-in-1, Thunderbolt 4)

Peak Performance, Total Connectivity

What’s in The Box:

Anker Apex 12-in-1 Thunderbolt 4 Docking Station (dock stand not included), 120W power adapter, 1.2m power cord, 0.7m Thunderbolt 4 cable, welcome guide，Anker PowerExpand USB-C to DisplayPort Adapter(Free Gift)

Note:1.Items will be shipped separately, please wait patiently .Any problems, please feel free to contact, thanks!2.We will not responsible for free gift ,thanks for understanding

Dimensions and Weight

Height: 186.4 mm / 7.3 in

Width: 73.7 mm / 2.9 in

Depth: 33.3 mm / 1.3 in

Weight: 467 g / 16.5 oz

Note:

Dock stand sold separately.

It is not recommended to use this product with an extension cord.

Connect virtually any device or peripheral you can imagine thanks to a Thunderbolt 4 upstream port, a Thunderbolt 4 downstream port, a USB-C Power Delivery port, 2 HDMI ports, an Ethernet port, SD card slot, a 3.5 mm AUX port, and 4 USB-A ports.

Thunderbolt 4 makes getting more from your laptop a breeze. Transfer files, connect an external monitor, and power your laptop all from a single port. That leaves plenty of ports free to accomplish all of your other tasks. Thunderbolt 4 even features compliance with a range of specifications including previous versions of Thunderbolt, USB4, DisplayPort, and PCI Express (PCIe).

Compatibility Information

• Compatible with Windows 10 laptops equipped with a Thunderbolt 4 port (Intel Evo Platform), and non-M1 MacBooks running macOS 11 (Big Sur) or later.
• Not compatible with Linux or ChromeOS laptops, Thunderbolt 3 Windows laptops, M1/M2 MacBooks, or M1 Max/Pro MacBooks running macOS 10.16 or earlier.

Note:

• If you cannot detect the dock after updating to macOS Ventura, please follow these steps: Privacy & Security > Allow accessories to connect.

macOS doesn't support Multi-Stream Transport (MST), and as such, all content displayed via the HDMI ports will be mirrored.

• The table above shows the maximum supported resolutions. Actual resolution varies based on the specifications of the host device.
• MacBooks with the AppleM1/M2chip only support single monitor display.
• Intel based MacBooks, Apple M1 Max/Pro MacBooks, andApple M2 Max/Pro MacBookssupport dual monitor display with extended desktop when using a USB-C to HDMI video adapter (not included). Connecting to two monitors using the two HDMI ports will only mirror your desktop.
• This dock can support up to three simultaneous monitor connections. The number of monitors that can be used with your laptop depends upon the power of your laptop and its graphics card capabilities. Not all laptops have the graphics capabilities to support multiple monitors and you may encounter display issues when attempting to use multiple displays.

Determining Your DisplayPort (DP) Version:The version of DP on your laptop, computer, or tablet directly determines the actual resolution when connecting to external monitors using the Anker hub. There are three simple ways to find out which version of DP your device has.

1. Ask your device manufacturer or seller directly.

2. If you're using a Windows device, you can tell which version of DP you have by checking your CPU generation.

• DP version 1.2 if your CPU is Intel generation 10 or earlier.
• DP version 1.4 if your CPU is Intel generation 11 or later.
• DP version 1.4 if you're using a workstation laptop with an NVIDIA GPU.

Don't know how to find your CPU generation? Simply go toThis PC(orMy Computer)> Propertiesand look for the number (shown in bold and underlined below):

Processer: Intel(R) Core i7-8850H CPU @ 2.60GHz 2.59Ghz

3. If you're using a MacBook, iMac, or iPad, you can find your DP version from the list below:

DP 1.4:iPad Pro 11-inch, iPad Pro 12.9-inch (3rd generation and later), MacBook Pro (16-inch, 2019), MacBook Pro (15-inch, 2017 and later), MacBook Pro (13-inch, 4 Thunderbolt 3 ports, 2020), MacBook Air (2020), MacBook Air (13-inch, M1, 2020), MacBook Pro (13-inch, M1, 2020), MacBook Pro (14-inch, 2021), MacBook Pro (16-inch, 2021), iMac (Retina 5K, 27-inch, 2017 and later), iMac (Retina 4K, 21.5-inch, 2017 and later), and iMac Pro (2017 and later)

DP 1.2:iPad Air (4th generation), MacBook Air (2018 and later), MacBook Pro (13-inch, 2016 and later), MacBook Pro (15-inch, 2016), iMac (non-Retina, 21.5‑inch, 2017), and Mac mini (2018)

• 90W Max Charging:Use a Thunderbolt 4 cable to keep your laptop powered up while you’re working.
• The USB-A data ports do not support charging.

FAQ

Q1: Can this dock support fast charging for my devices?

A1: This dock supports up to 90W of charging via the Thunderbolt 4 upstream port on the front of the dock (indicated with a computer icon). This means that if your laptop comes with a 100W or above power adapter, the charging speed will be slower than you’re used to. The USB-C Power Delivery port (indicated by “PD”) supports up to 20W fast charging for your phone. The Thunderbolt 4 downstream port supports 15W charging for smaller devices.

The USB-A data ports on the back of the dock do not support charging.

Q2: Will this dock work with any laptop? What kind of cable should I use to connect the dock to my laptop?

A2:No, this dock only works with Windows laptops equipped with a Thunderbolt 4 port (Intel Evo Platform), and non-M1 MacBooks running macOS 11 (Big Sur) or later. It is recommended to use a Thunderbolt 4.0 cable.

Q3: How to deal with screen drop, black screen, or screen flickering issues when connecting to an external monitor?

A3: After the dock has just been connected to the external monitor, it's normal for there to be some degree of flickering. It should go away in a few seconds. If this problem persists, try lowering the resolution.

If you experience any screen issues after waking up your laptop, restart the dock. If your laptop or the docking station has not been shut down for a long time and you’re experiencing screen issues, please restart the dock.

Q4: Sometimes the dock doesn’t automatically reconnect after I wake up or restart my laptop. What should I do?

A4: This situation doesn’t happen very often, but if you are having this problem, try disconnecting and reconnecting the Thunderbolt 4 cable.

Q5: Why does the dock feel warm?

A5: When charging or transferring data at high speed, the dock’s temperature may increase. Don't worry, this is within the normal limits of the dock’s operation. To avoid excessive heat, make sure not to place any objects on top of the dock or to cover the dock with anything.

What You Get:
Anker 777 Thunderbolt Docking Station (Apex, 12-in-1, Thunderbolt 4) / Apex 12-in-1 Thunderbolt 4 Docking Station (dock stand not included), 120W power adapter, 3.9 ft power cord, 2.3 ft Thunderbolt 4 cable,Anker PowerPort PD Nano Charger (Free Gift)

Note:

1.Items will be shipped separately, please wait patiently .Any problems, please feel free to contact, thanks!

2.We will not responsible for free gift ,thanks for understanding

• We gladly accept payment methods approved.
• Please make sure to submit the item number with your payment. If you have anyspecial requirements or requests, please contact via message.

• 30-day money-back guarantee for any reason.
  For 30 days after the date of purchase, return your undamaged Anker product andreceive a full refund for ANY reason.
• 12-24months warranty for quality-related issues(seeas description).

• Forpurchases under warranty, we take care of all quality-related issues witha REPLACEMENT. Reminder: Be sure to use your product as directed.
• Free user support
  Not sure how to get your Anker product to work properly Contact our world-class,friendly support team for quick solutions.
• Limitations

  • Our returns and exchange service is limited to all purchases made from anker_outlet_store. If you purchased through a different retailer, please contactthem directly. (Unauthorized reselling of Anker products is prohibited.)
  • Warranty-related shipping costs can only be covered in the country ofpurchase. If the product is taken outside the country of purchase, anyshipping costs will be the buyer's responsibility. Alternatively, we canoffer a 50% refund of the item's purchase price without the need to return.
• If returning an item, please ship it back within 30 days after you receiveapproval. Further delay may void your return.
• Friendly reminder
• When contacting us for help, be sure to have your Anker product handy fortroubleshooting!
  In the event our exchange policy changes, we?ll be sure to update this page.
